7 Replacement Procedures

Removing the rear covers

Agilent 990 Micro GC User Manual 95

Removing the rear covers

1 Remove power cord.

2 Remove sample-in and carrier gas connections.

3 Remove the rear covers by removing the four Torx T-10 screws, two for each cover.

Main rear cover

Torx T-10 screw
