4Sample Gas Handling

Sample inlet configurations

46 Agilent 990 Micro GC User Manual

Sample inlet configurations

There are many sample inlet configurations possible with the Agilent 990 Micro GC. The following

images include configurations using one and two GC units.

Figure 15. Sample inlet configurations

Scenario 1 Scenario 2 Scenario 3

Scenario 4

Scenario 6Scenario 5

Scenario 7 Scenario 8
