6 Channel Exchange and Installation

Channel removal procedure

Agilent 990 Micro GC User Manual 89

8 Press the spring sheet to remove the lock bar.

9 Lift both channel locking tabs to unlock the channel from the cabinet.

Lock bar

Spring sheet

Lock bar

Spring sheet
