Agilent Technologies ESG-D Series Manual Supplement

Using Wideband CDMA ESG-D Series Option H98 Signal Generators
System Configuration
3-16 Manual Supplement
System Configuration
The following illustration shows a typical system setup using the Option H98 signal
generator to test a base station in the uplink mode.
Figure 3-9 System Configuration for Wideband CDMA in the Uplink Mode
You must provide a logic level converter, as shown in the illustration above. The logic level
converter converts the SFN RST signal from the base station to a TTL signal that can be
used by the SFN RST Input connector on the rear panel of the Option H98 signal
generator. The base station’s 10 MHz reference output must be frequency-locked to its
internal baseband modulation.
