Softkey Reference ESG-D Series Option H98 Signal Generators

Wideband CDMA Softkeys

4-8 Manual Supplement

Table 4-1 Actual Symbol Rate as a Function of Channel Type versus

Selected Symbol Rate

Softkey Location: Mode > Wideband CDMA > Channel Setup > Channel Type

Status after Normal Preset: DTCH+ACCH

SCPI Commands and Command Queries:

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:TYPE

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:TYPE?

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:TYPE

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:TYPE?

CRC

Press this softkey to select CRC data insertion. When CRC is chosen, the

selected data pattern is appended to the back of the CRC. This

combination is then convolved, interleaved, and segmented into

timeslots.

Softkey Location:

Mode > Wideband CDMA > Channel Setup > More (1 of 2) >

Data Insertion > CRC

SCPI Commands and Command Queries:

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:INSert CRC

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:INSert?

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:INSert CRC

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:INSert?

Channel

Type

Selected Symbol Rate (in ksps)

32 64 64 voice 128 256

DTCH+ACCH 32 64 64 voice 128 256

ACCH 32 64 64 128 256

DTCH 32 64 64 voice 128 256

DTX 32 64 64 128 256

FACH 64 64 64 64 64

RACH 64 64 64 64 64

SDCCH 32 32 32 32 32

UPCH 32 64 64 128 256
