Agilent Technologies ESG-D Series Manual Supplement

ESG-D Series Option H98 Signal Generators Programming Information
Wideband CDMA Subsystem SCPI Command Reference
Manual Supplement 5-21
Table 5-5 provides some details about the parameters at each symbol rate.
Table 5-5 Parameters versus Symbol Rate
System Frame Number Type
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:PERCh[1]:SFNumber[:TYPE] INCR|FIX
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:PERCh[1]:SFNumber[:TYPE]?
Execute this command to setup the System Frame Number format.
The following System Frame Number types are assigned by appending the
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:PERCh[1]:SFNumber[:TYPE] command with one of
the following variables:
INCR Sets the System Frame Number type to increment.
FIX Sets the System Frame Number type to fixed.
Status after *RST: Increment
Parameter
Symbol Rate
32 ksps 64 ksps
64 ksps
voice
128 ksps 256 ksps
Data Bits
per Radio Frame
88 +
16 bit CRC
320 +
13 bit CRC
320 +
13 bit CRC
723 +
13 bit CRC
1446 +
2 by 13 bit CRC
Dummy Bits 48 1 1 8 8
Interleave Method 16 × 24 16 × 64 16 × 64 16 × 140 16 × 278
Bits per Radio Frame 384 1024 1024 2240 4448
Data Bits per Timeslot 24 64 64 140 278
