Agilent Technologies ESG-D Series Manual Supplement

Programming Information ESG-D Series Option H98 Signal Generators
Wideband CDMA Subsystem SCPI Command Reference
5-20 Manual Supplement
Multicode Symbol Rates
The following uplink multicode symbol rates are assigned by appending the
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:MCOD[1]:SRATe command with one of the
following variables:
SR32K Sets the multicode symbol rate to 32 kilosymbols per second.
SR64K Sets the multicode symbol rate to 64 kilosymbols per second.
SR128K Sets the multicode symbol rate to 128 kilosymbols per second.
SR256K Sets the multicode symbol rate to 256 kilosymbols per second.
Status after *RST: 32 ksps
64 ksps voice is not available in multicode mode.
NOTE Symbol rate is coupled to channel type. Table 5-4 shows actual symbol
rates set as a function of channel type and selected symbol rate.
Illegal assignments via remote (SCPI) commands default as shown in
Table 5-4.
Table 5-4 Actual Symbol Rate as a Function of Channel Type versus
Selected Symbol Rate
Channel
Type
Selected Symbol Rate (in ksps)
32 64 64 voice 128 256
DTCH+ACCH 32 64 64 voice 128 256
ACCH 32 64 64 128 256
DTCH 32 64 64 voice 128 256
DTX 32 64 64 128 256
FACH 64 64 64 64 64
RACH 64 64 64 64 64
SDCCH 32 32 32 32 32
UPCH 32 64 64 128 256
