Wideband CDMA Softkeys
4-30 Manual Supplement
TSlot
Press this softkey to enter the downlink/uplink channel or uplink
multicode time offset TSlot value.
TSlot in Downlink Mode
TSlot adjusts the number of symbols channel 1 radio frame is offset
from the Perch radio frame and long code phase zero. Total offset is
equal to TSlot plus TFrame. For additional information, see
“Understanding Time Offsets”on page 3-8.
TSlot in Uplink Mode
TSlot adjusts the number of symbols channels 1, 2 and 3 radio frames
are offset from long code phase 1280. Total offset is equal to TSlot plus
TFrame. For additional information, see“Understanding Time Offsets”
on page 3-8.
Softkey Location:
Mode>Wideband CDMA>Channel Setup>More (1 of 2)>
Time Offset>TSlot
Range: seeTable4-6
Status after Normal Preset: 0 symbols
Table 4-6 Symbol Rate Versus TSlot Range
Symbol Rate TSlot Values
32 ksps 0 to 19
64 ksps 0 to 39
64 kspsvoice 0 to 39
128 ksps 0 to 79
256 ksps 0 to 159
