Agilent Technologies ESG-D Series Manual Supplement

ESG-D Series Option H98 Signal Generators Softkey Reference
Wideband CDMA Softkeys
Manual Supplement 4-25
Symbol Rate
Press this softkey to set the symbol rate in kilosymbols per second
(ksps). The selected value is bolded.
32 ksps Sets the symbol rate to 32 kilosymbols per second.
64 ksps Sets the symbol rate to 64 kilosymbols per second.
64 ksps voice Sets the symbol rate to 64 kilosymbols per second voice.
Not available in multicode mode and uplink channels 2
and 3.
128 ksps Sets the symbol rate to 128 kilosymbols per second.
256 ksps Sets the symbol rate to 256 kilosymbols per second.
NOTE Symbol rate is coupled to channel type. Table 4-4 shows actual symbol
rates set as a function of channel type and selected symbol rate.
Illegal combinations are not selectable via the front panel. Illegal
assignments via remote (SCPI) commands will default as shown in the
following table.
Table 4-4 Actual Symbol Rate as a Function of Channel Type versus
Selected Symbol Rate
Channel
Type
Selected Symbol Rate (in kilosymbols per second)
32 64 64 voice 128 256
DTCH+ACCH 32 64 64 voice 128 256
ACCH 32 64 64 128 256
DTCH 32 64 64 voice 128 256
DTX 32 64 64 128 256
FACH 64 64 64 64 64
RACH 64 64 64 64 64
SDCCH 32 32 32 32 32
UPCH 32 64 64 128 256
