ESG-D Series Option H98 Signal Generators Softkey Reference

Wideband CDMA Softkeys

Manual Supplement 4-23

Short Code (Channel 1)

Press this softkey to set the short code for channel 1. To enter the short

code value, rotate the front-panel knob until the desired value is

displayed, use the up and down arrow keys, or enter the value using the

numeric keypad and press the

Enter terminator softkey. The range of

values allowed is dependent on the symbol rate.

If the symbol rate is changed to a new value, and the short code value

does not fall into the allowed short code range for the new symbol rate

value, the short code value is automatically set to the maximum short

code value that corresponds to the new rate. See Table 4-3.

Table 4-3 Symbol Rate Versus Channel 1 Short Code Range

Softkey Location: Mode > Wideband CDMA > Channel Setup > Short Code

Range: See Table 4-3

Status after Normal Preset: 8

SCPI Commands and Command Queries:

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:SCODe <value>

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:SCODe?

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:SCODe <value>

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:SCODe?

Symbol Rate Short Code Range

32 ksps 0 to 127

64 ksps 0 to 63

64 ksps voice 0 to 63

128 ksps 0 to 31

256 ksps 0 to 15
