Programming Information ESG-D Series Option H98 Signal Generators

Wideband CDMA Subsystem SCPI Command Reference

5-18 Manual Supplement

Short Code (Channels 2 and 3)

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:SCODe <value>

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:SCODe?

Execute this command to set the short code for uplink channel 2 or 3. This short code value

is used for channel 2 except in multicode during the Pilot and TPC symbols when the

primary channel short code value is used.

The range of values for channel 2 and 3 short code are coupled to the channel 1 symbol

rate, as previously described for Short Code (Channel 1). See Table 5-3.

NOTE Remote coupling between symbol rate and short code will fail to clamp

channels 2 and 3 short code to the correct upper limit.

To insure proper coupling between channels 2 and 3 short code and

symbol rate, always check the short code from the front-panel interface

and manually reconﬁgure any illegal values using the appropriate

softkeys.

Range: See Table 5-3

Status after *RST: 9

Symbol Rate

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:SRATe

SR32K|SR64K|SRV64K|SR128K|SR256K

[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:SRATe?

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:SRATe

SR32K|SR64K|SRV64K|SR128K|SR256K

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:SRATe?

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:SRATe

SR32K|SR64K|SR128K|SR256K

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:SRATe?

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:MCOD[1]:SRATe SR32K|SR64K|SR128K|SR256K

[:SOURce]:RADio:WCDMa[:BBG]:ULINK:MCOD[1]:SRATe?

Execute this command to set the symbol rate in kilosymbols per second (ksps). The symbol

rate choices are 32 ksps, 64 ksps, 64 ksps voice (not available in multicode mode and

uplink channels 2 and 3), 128 ksps, or 256 ksps.
