Agilent Technologies ESG-D Series Manual Supplement

ESG-D Series Option H98 Signal Generators Programming Information
Wideband CDMA Subsystem SCPI Command Reference
Manual Supplement 5-25
TSlot in Uplink Mode
TSlot adjusts the number of symbols channels 1, 2 and 3 radio frames are offset from long
code phase 1280. Total offset is equal to TSlot plus TFrame. For additional information, see
“Understanding Time Offsets”on page3-8.
Range: seeTable5-6
Status after *RST: 0 symbols
Table 5-6 Symbol Rate Versus TSlot Range
Uplink Channel Power
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:POWer <value>
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:POWer?
Execute this command to set the power level of the uplink channel 2 and 3 relative to
uplink channel 1.
Range:
±30 dB of the uplinkchannel 1 power level
Status after *RST: 0.00 dB
Uplink Interference Bits
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:PERCh[1]:UPIF <value>
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:PERCh[1]:UPIF?
Execute this command to enter the Perch1 uplink interference bit value.
Range:
0 to63
Status after *RST: 0
Symbol Rate TSlot Values
32 ksps 0 to 19
64 ksps 0 to 39
64kspsvoice 0 to 39
128 ksps 0 to 79
256 ksps 0 to 159
