Agilent Technologies ESG-D Series Manual Supplement

Softkey Reference ESG-D Series Option H98 Signal Generators
Wideband CDMA Softkeys
4-26 Manual Supplement
The following table provides some details about the parameters at each
symbol rate.
Table 4-5 Parameters versus Symbol Rate
Softkey Location: Mode > Wideband CDMA > Channel Setup > Symbol Rate
Choices: 32 ksps, 64 ksps, 64 ksps voice, 128 ksps, 256 ksps
Status after Normal Preset: 32 ksps
SCPI Commands and Command Queries:
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:SRATe
SR32K|SR64K|SRV64K|SR128K|SR256K
[:SOURce]:RADio:WCDMa[:BBG]:DLINK:CHANnel[1]:SRATe?
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:SRATe
SR32K|SR64K|SRV64K|SR128K|SR256K
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel[1]:SRATe?
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:SRATe
SR32K|SR64K|SR128K|SR256K
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:CHANnel2|3:SRATe?
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:MCOD[1]:SRATe
SR32K|SR64K|SR128K|SR256K
[:SOURce]:RADio:WCDMa[:BBG]:ULINK:MCOD[1]:SRATe?
Parameter
Symbol Rate
32 ksps 64 ksps
64 ksps
voice
128 ksps 256 ksps
Data Bits
per Radio Frame
88 +
16 bit CRC
320 +
13 bit CRC
320 +
13 bit CRC
723 +
13 bit CRC
1446 +
2 by 13 bit CRC
Dummy Bits 48 1 1 8 8
Interleave
Method
16 × 24 16 × 64 16 × 64 16 × 140 16 × 278
Bits per Radio
Frame
384 1024 1024 2240 4448
Data Bits per
Timeslot
24 64 64 140 278
