Agilent Technologies G1313A

168
Parts and Materials
Injection-Valve Assembly
Injection-Valve Assembly
Table 23 Injection-Valve Assembly for G1313A / G1329A
,WHP 'HVFULSWLRQ 3DUW1XPEHU
1 Injection-valve assembly, includes items1 – 6 0101-0921
2 Isolation seal 0100-1852
3 Rotor seal (Vespel) 0100-1853
3 Rotor seal (Tefzel) 0100-1849
4 Stator face 0100-1851
5 Stator head 0100-1850
6 Stator screws 1535-4857
Table 24 Micro Injection-Valve Assembly for G1389A
The micro injection valve assembly has no ceramic stator face
,WHP 'HVFULSWLRQ 3DUW1XPEHU
1 Micro Inj.-valve assy, incl. items 1 – 2 – 3 – 5 – 6 0101-1050
2 Isolation seal 0100-1852
3 Micro rotor seal (Vespel) 0100-2088
5 Micro Stator head 0100-2089
6 Stator screws 1535-4857
