Agilent Technologies G1313A

165
Parts and Materials
Analytical-Head Assembly
Analytical-Head Assembly
Table 19 Analytical-Head Assembly (100 µl) for G1313A / G1329A
,WHP 'HVFULSWLRQ 3DUW1XPEHU
Analytical head assembly, includes items 1 – 6 01078-60003
1 Screws 0515-0850
2 Plunger assembly 5063-6586
3 Adapter 01078-23202
4 Support seal assembly 5001-3739
5 Metering seal (pack of 2) 5063-6589
6 Head body 01078-27710
Screw M5, 60 mm lg, for mounting of assembly 0515-2118
Table 20 Analytical-Head Assembly (40 µl) for G1389A
,WHP 'HVFULSWLRQ 3DUW1XPEHU
Micro Analytical head assembly 40 µl, includes items 1 – 6 G1377-60013
1 Micro Plunger assembly 5064-8293
2 Screws 0515-0850
3 Adapter 01078-23202
4 Micro seal support assembly G1377-60002
5 Metering seal (pack of 1) 5022-2175
6 Head body G1377-27700
Screw M5, 60 mm lg, for mounting of assembly 0515-2118
