Theory of Operation
Optional Interface Boards
Optional Interface Boards
The Agilent 1100 Series modules have one optional board slot that allows
addition of an interface board to the modules.
BCD Board
The BCD board provides a BCD output for the bottle number of the
Agilent 1100 Series autosampler and four external contacts. The external
contact closure contacts are relay contacts. The maximum settings are:
30 V (AC/DC); 250 mA (fused). There are general purpose cables available
to connect the BCD output, see “BCD Cables” on page 195 and the external
outputs, see “External Contact Cable” on page 198 to external devices.
Table 47 Optional Interface Boards
'HVFULSWLRQ 3DUW1XPEHU
BCD Board G1351-68701
Fuse 250 mA (four are on the board) 2110-0004
LAN Board (see next page for details)
