Agilent Technologies Helium Leak Detector
DRAFT 12/11/17
127
7.4.6.4 System Information
❑ Press System Information on the Menus screen.
The System Information screen appears (Figure 7-14).
This screen gives detail
s of the installed software version, spectrometer parameters
and the turbo frequency.
Figure 7-14 System Information
Table 7-2 System Information Screen Conditions
Condition Display Description
Ion Source Filament
See Section 7.4.3 “Manual Tuning”
on page 118.
Filament 1 Off Filament 1 is selected and not lit.
Filament 1 On Filament 1 is selected and lit.
Filament 2 Off Filament 2 is selected and not lit.
Filament 2 On Filament 2 is selected and lit.
Gain Gain (Gain Value) Displays the gain that applied to the
leak
rate. The actual helium signal is
multiplied by the gain value to read
the correct, calibrated leak rate.
Software Version and
Agilent Web site
Shows the software version of the CPU
board.
