Section 3. Home Screen
3.1 Home Screen
The Home screen displays a summary of the following status and configuration settings:
Figure 3-1 shows the screen controls.
Figure 3-1 Home Screen
❑ Digital Leak Rate Display ❑ Test Port Pressure ❑ Gross Test button (not
shown)
❑ Leak Detector Status 
(Table 3-1 on page 58)
❑ Condition Indication
(Table 3-2 on page 58)
❑ Reject Status Indicator ❑ System Ready Indicator
❑ Menus button
Valve state
Zero
Alphanumeric
leak rate
Units of
measurement
Menu
Power Off
Zero Enable Graph
Speaker Volume/Control
Home
Vent
Test/Hold
Setpoints Status window
Application
(Active)
