Agilent Technologies Helium Leak Detector
DRAFT 12/11/17
35
1.3.3 Bench System Installations
Figure 1-13 and Figure 1-17 represent the process for installation of the bench system
version of the Agilent Technologies Helium Mass Spectrometer Leak Detector.
Figure 1-13 is a drawing of a Bench Mount Leak Detector with External DS302 Wet Rotary
Vane Pump, Model G8612A with individual components shown.
Figure 1-13 Bench Mount Leak Detector with External DS302/DS602 Wet Rotary Vane Pump,
Model G8612A\GS8612D
Figure 1-14 is a drawing of a Bench Mount Leak Detector with External TS620 Dry Scroll
Pump, Model G8612B with individual components shown.*
NOTE Cut the ¾” black tubing into two equal parts as shown.
Figure 1-14 Bench Mount Leak Detector with External TS620 Dry Scroll Pump, Model G8612
Note orientation
of VPI valve
To Next Page
