Storage Ambient
Conditions
Relative humidity: 0% to 95%, non-condensing. Temperature:
20 °C (4 °F) to +60 °C (140 °F)
Power Requirements
Input Power
❑ 100 VAC, 50 Hz, 20 A
❑ 115 VAC, 60 Hz, 20 A or
❑ 230 VAC, 50/60 Hz, 12 A
Max. Branch Circuit Breaker: 20A with motor-rated time delay.
Dimensions
See outline drawings (Figure 1-1 on page 27 to Figure 1-14 on page 35).
Weight G8610A with built in DS40M pump: 77 lb./35 kg*
G8611A w/DS-302 rotary vane pump on cart: 172 lb./78 kg*
G8611C w/IDP-15 dry scroll pump on cart: 194 lb./88 kg*
G8611B w/TS-620 dry scroll pump on cart: 192 lb./87 kg*
G8610B with IDP-3 dry pump: 77 lb./35kg*
* Add 1.0 kg if the Wireless Remote and optional I/O features are installed.
Touch Panel display
8.4 inch color TFT LCD module G084SN03 V3.
The screen format is intended to support the SVGA (800(H) x 600(V)) screen and 16.2M (RGB
8-bits) or 262k colors (RGB 6-bits). Viewing area 175.1 mm X 132.2 mm
Regulatory CAN/CSA-C22.2 No. 61010-1-12 - Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 1: General Requirements
UL Std. No. 61010-1, 3rd Edition - Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 1: General Requirements
EMC Emissions and Immunity -ETSI EN 301 489-1 v2.2.0 (2017-03) Electromagnetic
Compatibility and Radio Spectrum Matters (ERM); Electromagnetic Comparability
(EMC) standard for radio equipment and services; Part1: Common technical
requirements:
❑ ETSI EN 301489 v2.2.1 (2012-09) Electromagnetic Compatibility and Radio Spec-
trum Matters (ERM); Electromagnetic Comparability (EMC) standard for radio equip-
ment; Part 17: Broadband Data Transmission Systems
❑ EN 61326-1: 2013 EMC requirements for Electrical equipment for measurement,
control and laboratory use - General Use
For particular Safety and EMC Standards see Declaration of Conformity.
Single rotation speed
Turbo: 70K RPM
Leak test range
E-11 to E-4
Maximum spectrometer
pressure
1E-04 Torr - Filament turns off when pressure exceeds this point
Table C-1 Leak Detector Series Specifications (Continued)
Specifications
Agilent Technologies Helium Mass Spectrometer Versions
