Agilent Technologies G8610A User Manual

Agilent Technologies Helium Leak Detector
26
DRAFT 12
/11/17
CAUTION The usage of a longer cable for the parallel I/O output
connection with an external PLC is fully responsibility of the
user. Some EMC prevention measure may be required by the
user.
❑ USB type A connector and one located on the back of the leak detector.
NOTE USB features are for updated software downloads only.
Table 1-1 Series Leak Detector Configurations and Part Numbers
Model
Number
Leak Detector
Type
Agilent
P/N
Mains
Voltage 50/60 Hz (Amp)
G8610A
(DS40M)
Portable G8610-64000 115 VAC 2.0/2.3
Portable G8610-64001 230 VAC 1.0/1.3
G8610B
(IDP-3)
Portable G8610-64002 100 VAC 2.2/2.4
Portable G8610-64003 115 VAC 2.4/2.2
Portable G8610-64004 230 VAC 1.2/1.2
G8611A
(DS302)
Mobile G8611-64000 115 VAC 9.0/5.4
Mobile G8611-64001 230 VAC 4.4/2.5
G8611B
(TS620)
Mobile G8611-64002 115 VAC 7.7/6.8
Mobile G8611-64003 230 VAC 3.8/3.4
G8611C
(IDP
-15)
Mobile G8611-64004 115 VAC 6.0/4.2
Mobile G8611-64005 230 VAC 2.8/3.0
G8611D
(DS602)
Mobile G8611-64006 230 VAC 4.4/2.8
G8612A
(DS302)
Benchtop G8612-64000 115 VAC 9.0/5.4
Benchtop G8612-64001 230 VAC 4.4/2.5
G8612B
(T
S620)
Benchtop G8612-64002 115 VAC 7.7/6.8
Benchtop G8612-64003 230 VAC 3.8/3.4
G8612C
(IDP-15)
Benchtop G8612-64004 115 VAC 6.0/4.2
Benchtop G8612-64005 230 VAC 2.8/3.0
G8612D
(DS602)
Benchtop G8612-64006 230 VAC 4.4/2.8
Outline drawings for each configuration are shown in Section 1.1.1 “Leak Detector
Configurations”.

Agilent Technologies G8610A Specifications
