Agilent Technologies Helium Leak Detector
52
DRAFT 12
/11/17
Wireless Remote Control This provides:
❑ RF communication between the leak detector (with base station or
host) and the Wireless Remote unit from a distance up to 100 m
(300 ft).
❑ The ability to enter the leak detector unit into Test and Hold modes
from the Wireless Remote unit's keypad.
❑ The ability to read the leak detector’s leak rate in a linear and log-
arithmic bar graph format with a numeric range indicator and Sys-
tem status in alphanumeric format on the Wireless Remote unit's
Touch Panel display.
❑ Configuration up to 10 different leak detector unit’s for wireless
control by toggling through a MAC address list using one Wireless
Remote unit
Discrete I/O Control This provides 12 outputs and 8 inputs lines, optically isolated, to
control the leak detector using an external PLC via a 25-pin DB25
female connector and a user-provided parallel cable.
Table 1-4 Features (Continued)
Feature Description
