Introduction 2
Agilent SPS 4 Autosampler User’s Guide 23
Weights and Dimensions
*: For the mainframe only. Another package is added for accessory kits.
Key Specifications
WARNING
Danger to hands and feet. When packaged the Agilent SPS 4 weighs approximately
18.6 kg (41.0 lbs). To avoid injury to personnel or damage to equipment, always use a
fork lift or other suitable lifting device when moving the instrument. If a fork lift is
not available, the Agilent SPS 4 will need to be lifted by two people.
Table 3 Weights and dimensions
Weights and Dimensions Specification
Length: 600 mm (23.6 in)
Depth: 363 mm (14.3 in)
Height: 510 mm (20.1 in)
Shipping Dimensions: *
(Packed in a Single Box)
812 mm x 532 mm x 714 mm,
32.0 in x 20.9 in x 28.1 in (approx.)
Net Weight * 15 kg, 33.1 lbs (approx.)
Shipping Weight: * Single Box 18.6 kg, 41.0 lbs (approx.)
Table 4 Agilent SPS 4 Key Specifications
Parameter Specification
Max. Number of Sample Racks 4
Max. Number of Standards racks 1
Max. Tube Height 150 mm (5.9 in)
Probe Wash Options Fixed Wash Reservoir (FWR) — single or optional dual
port
Wash Pump 3 individual channels, speed controlled by the instrument
control software
