Installation 3
Agilent SPS 4 Autosampler User’s Guide 51
Notes on Lifting the Autosampler
When lifting the autosampler:
• Ensure the power is off and the power and USB cables are
disconnected.
• Remove any accessories fitted to the rack location mat such as sample
racks, standards rack, the fixed wash reservoir and any associated
tubing.
• Remove the clear side covers (if fitted).
• It is advisable to lift the autosampler with two people positioning their
hands through the end frames at either end as shown in Figure 18.
Figure 18 Lifting positions for removing the autosampler
One person to lift
with hands through
left window
One person to lift
with hands through
right window
CAUTION
The autosampler should never be carried by the probe carriage or the wash pump
tubing ducting.
