VS Series Helium Mass Spectrometer Leak Detectors
1-12
DRAFT 4/
23/15
1.3.2 Removing the Shipping Bolts: MD/BD30+ and MD/BD15
The MD/BD30+ and MD/BD15 units come with a shipping bolt (MD/BD30+) and shipping
locks (MD/BD15).
CAUTION These shipping bolts and shipping locks must be disengaged
before use to avoid damaging the units.
1.3.2.1 MD/BD30+
This unit comes with the TriScroll 620 pump.
1. Remove the cover by removing the four screws (two shown in Figure 1-6) using an M5
wrench (two on each side). Figure 1-6 shows an IDP-15 unit.
Figure 1-6 Cover Bolts
