Agilent Technologies VS Series User Manual

VS Series Helium Mass Spectrometer Leak Detectors
2-30
DRAFT 4/
23/15
2.2.4.6 System Information
❑ Press System Information on the Menus screen.
The System Information screen appears (Figure 2-15).
Details of the current leak detector setup and operating conditions are displayed.
The left column displays filament status, reject set point status, turbo status, auto
sequencer status, and audio set point status. The right column displays the
calibrated leak setting, leak rate range settings, and the sensitivity configuration.
Table 2-6 describes the displayed system information in detail.
Figure 2-15 System Information
a
Table 2-6 System Information Screen Conditions
Condition Display Description
Audio Set Point
See Section 2.2.4.2 “Reject and
Audio Set Points” on page 2-19.
Audio Set Point:
Active
Audio Set Point is active.
Audio Set Point:
Inactive
Audio Set Point is inactive.
Auto Sequencer
See Section 2.2.4.3 “Auto
Sequencer” on page 2-22.
Auto Sequencer: On Auto Sequencer (automatic test cycle)
is enabled.
Auto Sequencer: Off Auto Sequencer (automatic test cycle)
is disabled.
Calibration Set-Up
See Section 2.2.4.1 “Calibration
Set-Up” on page 2-17.
Int Cal Leak System is set to calibrate to the internal
standard leak.
Ext Cal Leak System is set up to calibrate to an
external standard leak.
- 10
SYSTEM INFORMATION
FILAMENT 1 ✔ INTERNAL CAL LEAK
AUTO RANGING
CPU: LD01.00.02
LCD: DDO1.00.02
WWW.AGILENT.COM/
0 1 2 3 4 5 6 7 8 9 10
DONE
A blue check
denotes a good
filament; red is bad
.
GAIN: 1.5
Displays the Gain
