VS Series Helium Mass Spectrometer Leak Detectors
4-6
DRAFT 4/
23/15
4.3 Spare Parts List
Table 4-4 Leak Detector Spare Parts
Assembly Part Number
Motherboard PCB R2101501
CPU PCB R2361303
Ion Source PCB R2120502
Valve Driver PCB R2104502
Exchange Turbo Pump Controller PCB EX9699518M001
Front Panel Assembly R2926301
Spectrometer Assembly, Exchange EXR2040301
Spectrometer Header Ass'y, Exchange EXVSFLDHHA
Ion Source Replacement Kit VSFLDHIS
Filament Replacement Kit* VSFLDFR, VSFLDHFR
Ion Box Replacement Kit VSFLDIB, VSFLDHIB
Metal Gasket Kit VSFLDMG
Valve Block O-ring Kit VSFLDOV
Calibrated Leak, VS Internal VSFLDCL
TC Gauge R3391301
Fan Assembly VSFLDFN
Power Supply VSFLDPS
Spec Tube Cleaning Kit 670029096
Fan, IDP3 Pump VSFLDFN3
Back to Air, Maintenance Kit
(V9) PD03 & PR02
(April 2010)
VSFLDV9
PD03 Exhaust Valve, V8 VSFLDV8
Tur bo Pu mp, Ex ch ang e EX8699367
Valve (V1 to V5, V7) R2010302
V6 Calibrated Leak Valve (prior to April 2010),
DS42 Gas
Ballast Valve (PR02)
R2011302
V6 Calibrated Leak Valve (April 2010) G8603-60002
MD/BD Exhaust Valve V8
0101-1555
* VS units sold after 18 Aug 2009 with serial number ST0908L012 or higher use filament kit VSFLDHFR
