tips:
a.
There are large errors in selecting points on the map. Please pay attention to safety obstacles and
reserve sufficient safety margins to ensure flight safety.
b.
Please use the referential points correction before operation, and correct the referential points in
the work area to the drone position to reduce the errors. For detailed operation methods, please
refer to the function of "reference point correction".
accuracy is high. Suitable for complex land with many obstacles.
c.
Drone mark is to operate the drone to reach the boundaries of the plot to perform the
operation. The operation is relatively simple and the accuracy is high, but it is difficult to apply to
the plot with complicated boundaries and many obstacles. It is suitable for large plots with
smooth borders and few obstacles.
d.
Network mark is the use of network base stations for high-precision marking, you need to
hold the rover and mobile phones along the boundary of the plot and obstacles, the operation is
more complicated, but the accuracy is high. It is suitable for large and complicated plots with
many obstacles.This function is only restricted to Chinese mainland.
e.
Base station marking is the use of mobile base stations for high-precision mark, you need
to mount the base station well, Then the mobile phone is connected to the rover ( Needs to turn
on Bluetooth in the mobile phone), and the base station rover is used to connect the base station.
Finally, it is necessary to take the rover with the mobile phone to dot along the boundary of the
parcel and the obstacle. The operation is more complex, but it can maintain high precision and
accuracy stably.It is suitable for large and small blocks with complex and many obstacles
5.6.1.1. Map marking
Use the map reference location to mark.
Operation process: Open the APP to input the mission planning interface——click "Add plot"—
— select map marking—— connection is successful—— drag the map to the area that requires
work——drag the map to make the center of the map to locate the icon
is aligned with the
boundary points, obstacles, reference points of the work area, then mark——save the plot after
mapping.
5.6.1.2. Remote control marking
The remote control has a built-in GPS positioning module, and users can use the remote control
for mark planning.
Operation process: Open the remote control
— —
open the APP to input the mission planning
interface
——
click "Add a plot"
——
select the remote control mark
——
in the popup window
please select the remote control Bluetooth and then connect — — successful connection — —
ensure there is no obstruction above the remote control ——you can mark when the status bar
shows blue or orange
— —
hold the remote control around the boundary
of
the
plot,
add
boundary points of obstacles, obstacle points, reference points — — click to save the plot after
mapping.
