AGR A22 2021 - Route Editing and Planning

C.
Connect the remote controller to the rover (the ground station needs to turn on
Bluetooth),Connect the base station point collector according to the interface prompt.
D.
The power of the four corner status indicator is defined as follows.
Four corner LED status capacity
Green light always on > 80%
Yellow and green flicker alternately 60% ~ 80%
The yellow light is always on 40% ~ 60%
Red and yellow flicker alternately 20% ~ 40%
Red light always on < 20%
5.6.2. Edit route
5.6.2.1. Enter route edit
Two ways to enter the plot route editing:
Enter the APP execution working interface——click "Start working"——enter the route working
——select the plot——click to edit the route.
Enter the APP route planning interface——click "My Plot"——select the plot to be operated—
—click to call the plot——click to edit the route.
Enter the editing route, you can edit the working distance, safety margin, obstacle margin,
reference point correction (route translation), heading direction, heading split, and transit point.
Row spacing of working
The distance that the drone can traverse each time, the adjustable range is 2-10m. Please
