Technical specifications
Model： 3WWDZ-20A
Frame
Wheelbase：1564mm
Size：1210*1210*570mm
Package Size：1200*800*530mm
power system
Motor
Stator size：96x16mm
KV value：100 rpm/V
Maximum pull force：26.5kg/rotor
Maximum power：1500W/rotor
Electrical regulation
Maximum working current (continuous)：150A
Maximum working voltage：58.8V
Foldable propeller (36120): diameter x pitch36×120 inch
Flight parameters
Total weight (excluding battery)：19.6kg
Standard takeoff weight：48.1kg
Effective takeoff weight：50.1kg
RTK on：horizontal±10cm，vertical±10cm
RTK off：horizontal±60cm，vertical±60cm
RTK/GNSS frequency band：BDS B1/B2，GPS L1/L2，GLONASS L1/L2，QZSS L1/L2，SBAS L1
Power battery model：QF14220(22000mAh-51.8v)
Maximum power consumption：9000W
Hovering power consuption：5500W
Hover time：10min（Takeoff weight 40.3kg）
Maximum pitch angle：25°
Maximum operating flight speed：10m/s
Maximum flying speed：10m/s
Maximum affordable wind speed：8m/s
Maximum takeoff altitude：2000m
Recommended working environment temperature：0℃ to 40℃
FPV camera
Resolution：720P
Filed View（FOV）：horizontal 120°，vertical 90°
Spraying system
Tank
Volume：22L
