Alcatel-Lucent 7210 SAS M Configuration Guide

System Management
7210 SAS M, T, X, R6 Basic System Configuration Guide Page 427
NOTE: On 7210 SAS-X, the limit applies to the total number of slices that can be used by ACLs
across all match criteria supported on the node. Individual limits per match criteria are different and
are noted under the CLI description for those criteria.
ipv4-ipv6-128-match-enable
Syntax [no] ipv4-ipv6-128-match-enable
Context configure>system>resource-profile>ingress-internal-tcam>acl-sap-ingress
Description This command allows the user to allocate maximum resources for use by ingress filter policies using
ipv6 criteria with 128-bit IPv6 addresses.
The resources can be shared with IPv4 ingress filter policies. Please see the 7210 SAS Router
Configuration guide for more information on how to allow filter policies using IPv4 criteria to share
resources with filter policies that use IPv6 criteria with 128-bit address and resource allocation details
and fields available for use.
With the no form of the command, the software does not allocate any resources for use by ingress
filter policies using ipv6 criteria with 128-bit IPv6 addresses. If no resources are allocated for use,
then the software fails all attempts to associate a service entity (For example: SAP, IP interface, etc.)
with a ingress filter policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter match criteria.
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 5
7210 SAS-X (per node) 0 6 2
7210 SAS-T Access-Uplink
mode (per node)
0 7 3
7210 SAS-T Network Mode
(per node)
0 6 3
7210 SAS-R6 (per IMM) 0 5 2
