Alcatel-Lucent 7210 SAS M Configuration Guide

System Resource-Profile Commands
Page 432 7210 SAS M, T, X, R6 Basic System Configuration
Guide
max — It is a special keyword. If user specifies max, then the software allocates one chunk when the
first SAP is associated with a ingress filter policy using this match criteria. It continues to allocate
resources to SAPs associated with a ingress filter policy using this criteria, as long as the total amount
of resources allocated does not exceed the resources allocated to ingress filter policies (configured
with the command config> system> resource-profile> ingress-internal-tcam> acl-sap-ingress
command) and chunks are available for use.
eth-cfm
Syntax [no] eth-cfm
Context configure>system>resource-profile>ingress-internal-tcam
Description On 7210 SAS-M, 7210 SAS-T and 7210 SAS-X, the behavior is as follows:
This command provides the context to allocate resources for CFM UP MEPs. With the no form of the
command, software does not allocate any resources for use by CFM UP MEPs.
On these platforms, there is no need for the user to allocate resources explicitly for Down MEPs.
On 7210 SAS-R6, the behavior is as follows:
This command provides the context to allocate resources for CFM Down MEPs. The no form of the
command is not supported.
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 max
7210 SAS-X (per node) - - -
7210 SAS-T Access-Uplink
mode (per node)
0 7 max
7210 SAS-T Network Mode
(per node)
0 6 max
7210 SAS-R6 (per IMM) 0 max number
of slices
assigned to
acl
max
