System Management
7210 SAS M, T, X, R6 Basic System Configuration Guide Page 431
mac-match-enable
Syntax [no] mac-match-enable
Context configure>system>resource-profile>ingress-internal-tcam>acl-sap-ingress
configure>system>resource-profile>ingress-internal-tcam> qos-sap-ingress-resource
Description This command allows the user to allocate maximum resources for use by ingress filter policies using
mac criteria. Or when used under the qos-sap-ingress-resource context, its used to allocates resources
for use by SAP ingress QoS policies using MAC criteria (any).
The resources cannot be shared with policies that use either IPv4 or IPv6 match criteria. For more
details about the resource allocation for ingress filter policy and fields available for use with ingress
filter policy please refer the 7210 SAS-M, X, T and R6 Router Configuration user guide. For more
details about the resource allocation for SAP ingress QoS policy please refer to 7210 SAS-M and
7210 SAS-X QoS user guide.
With the no form of the command, the software does not allocate any resources for use by ingress
filter policies or SAP ingress QoS policies using mac criteria. If no resources are allocated for use,
then software fails all attempts to associate a service entity (For example: SAP, IP interface, etc.) with
a ingress filter policy or SAP ingress QoS policy using this match criteria.
NOTE: This command is not available on 7210 SAS-X.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter match criteria.
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 max
7210 SAS-X (per node) 0 2 max
7210 SAS-T Access-uplink
mode (per node)
0 7 max
7210 SAS-T Network Mode
(per node)
0 6 max
7210 SAS-R6 (per IMM) 0 max number
of slices
assigned to
acl
max
