Alcatel-Lucent 7210 SAS M Configuration Guide

System Management
7210 SAS M, T, X, R6 Basic System Configuration Guide Page 465
IPv4-IPv6
Resource
Displays the resources configured for use by ingress ACL poli-
cies that use ipv6 128-bit address match-criteria.
Disable – No resources are allocated for use by this feature.
Hence, no policies of this type can be associated to a SAP.
Mac Resource
Displays the resources configured for use by ingress ACL poli-
cies that use mac-criteria.
Disable – No resources are allocated for use by this feature.
Hence, no policies of this type can be associated to a SAP.
IPv6-64 bit
Resource
Displays the resources configured for use by ingress ACL poli-
cies that use ipv6 64-bit address match-criteria.
Disable – No resources are allocated for use by this feature.
Hence, no policies of this type can be associated to a SAP.
Eth CFM
Groups the context for resources consumed by Ethernet CFM
applications.
up-mep
Displays the resources configured for use by UP MEP.
Disable – No resources are allocated for use by this feature.
Therefore, no UP MEPs can be created.
Sap Ingress QoS
resource
The total amount of ingress internal CAM chunks configured for
use by SAP ingress classification.
Mac and IPv4
Resource
The total amount of egress internal CAM chunks configured for
use by MAC and IPv4 egress ACL match criteria policies.
Mac-only Resource
The total amount of egress internal CAM chunks configured for
use only by MAC egress ACL match criteria policies.
IPv6 128 bit
Resource
The total amount of egress internal CAM chunks configured for
use only by IPv6 egress ACL match criteria policies (128-bit
IPv6 address can be specified in the match criteria).
Mac and IPv6 64
bit Resource
The total amount of egress internal CAM chunks configured for
use by MAC and IPv6 egress ACL match criteria policies (only
64-bit higher order bits of the IPv6 address can be specified in
the match criteria).
system-max-ecmp
Displays the maximum number of routes that will be allocated
per IP destination/prefix in hardware when the user enables
ECMP path sharing using multiple routes.
Sap Egress ACL
resource
Displays the egress ACL resource allocation configured for vari-
ous match criteria.
Egress Internal
CAM
Displays the resource allocation configured for the egress inter-
nal CAM.
Table 33: Show system resource-profile output fields.
Label Description
