Publication 1762-UM001D-EN-P - March 2004
A-14 Specifications
Vendor I.D. Code 11111
Product Type Code 10 10 10 10 10
Product Code 75 67 66 65 64
(1) The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues to convert the analog input up to the maximum
full scale range.
(2) Repeatability is the ability of the module to register the same reading in successive measurements for the same signal.
(3) Rated working voltage is the maximum continuous voltage that can be applied at the terminals with respect to earth ground.
Table A.19 General Specifications
Specification 1762-IF2OF2 1762-IF4 1762-OF4 1762-IR4 1762-IT4
Table A.20 Input Specifications
Specification 1762-IF2OF2 1762-IF4 1762-IR4 1762-IT4
Number of Inputs 2 differential (unipolar) 4 differential (bipolar) 4 4 input channels plus 1
CJC sensor
Update Time (typical) 2.5 ms 130, 250, 290, 450, 530
ms (selectable)
Input filter and
cofiguration dependent
NA
A/D Converter Type Successive
approximation
Successive
approximation
Delta-Sigma Delta-Sigma
Common Mode Voltage
Range
(1)
±27V ±27V NA ±10V
Common Mode
Rejection
(2)
> 55 dB at 50 and 60 Hz > 55 dB at 50 and 60 Hz >110 dB at 50 Hz (with 10
or 50 Hz filter)
>110 dB at 60 Hz (with 10
or 60 Hz filter)
>110 dB at 50 Hz (with 10
or 50 Hz filter)
>110 dB at 60 Hz (with 10
or 60 Hz filter)
Non-linearity (in percent
full scale)
±0.1% ±0.1% ±0.05% NA
Typical Overall
Accuracy
(3)
±0.5% full scale at 0 to
55°C
±0.3% full scale at 25°C
±0.3% full scale at 0 to
55°C
±0.24% full scale at 25°C
±0.5°C (F°) for Pt 385 NA
Input Impedance Voltage Terminal: 200KΩ
Current Terminal: 250Ω
Voltage Terminal: 200KΩ
Current Terminal: 275Ω
>10 ΜΩ >10 ΜΩ
Current Input Protection ±32 mA ±32 mA NA NA
Voltage Input Protection ±30V ±30V NA NA
Channel Diagnostics Over or under range or
open circuit condition by
bit reporting for analog
inputs.
Over or under range or
open circuit condition by
bit reporting for analog
inputs.
Over or under range or
open circuit condition by
bit reporting for analog
inputs.
Over or under range or
open circuit condition by
bit reporting for analog
inputs.
(1) For proper operation, both the plus and minus input terminals must be within ±27V (±10V for 1762-IT4) of analog common.
(2) V
cm
= 1 V
pk-pk
AC
(3) V
cm
= 0 (includes offset, gain, non-linearity and repeatability error terms)
