Allen-Bradley MicroLogix 1200 User Manual

Publication 1762-UM001D-EN-P - March 2004
E-12 Connecting to Networks via RS-232 Interface
Modbus Communication
Protocol
Modbus is a Half-Duplex, master-slave communications protocol. The
Modbus network master reads and writes coils and registers. Modbus
protocol allows a single master to communicate with a maximum of
247 slave devices. MicroLogix 1200 controllers support Modbus RTU
Master and Modbus RTU Slave protocol.
For more information on configurating your MicroLogix 1200
controller for Modbus protocol, refer to the MicroLogix 1200 and
1500 Programmable Controllers Instruction Set Reference Manual,
publication 1762-RM001. For more information about the Modbus
protocol, see the Modbus Protocol Specifications (available from
http://www.modbus.org
).
ASCII
ASCII provides connection to ot her ASCII devices, such as bar code
readers, weigh scales, serial printers, and other intelligent devices.
You can use ASC
II by configurin g the RS-232 port, channel 0 for ASCII
driver. Refer to the MicroLogix 1200 and MicroLogix 1500
Programmable Controllers Instruction Set Reference Manual,
publication 1762-RM001 for detailed configuration information.

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
