Allen-Bradley MicroLogix 1200 User Manual

1 Publication 1762-UM001D-EN-P - March 2004
Appendix A
Specifications
Controller Specifications
Table A.1 General Specifications
Description 1762-
L24AWA
L24AWAR
L24BWA
L24BWAR
L24BXB
L24BXBR
L40AWA
L40AWAR
L40BWA
L40BWAR
L40BXB
L40BXBR
Dimensions Height: 90 mm,
1
04 mm (with DIN latch o pen)
Width: 110 mm, Depth: 87 mm
Height: 90 mm
104
mm (with DIN latch open )
Width: 160 mm, Depth: 87 mm
Shipping Weight 0.9 kg (2.0 lbs) 1.1 kg (2.4 lbs)
Number of I/O 14 inputs and 10 outputs 24 inputs, 16 outputs
Power Supply 100 to 240V ac
( -15%, +10%)
at 47 to 63 Hz
24V dc
( -15%, +10%)
Class 2
SELV
100 to 240V ac
( -15%, +10%)
at 47 to 63 Hz
24V dc
( -15%, +10%)
Class 2
SELV
Heat Dissipation See Appendix F
Power Supply Inrush 120V ac: 25A for 8 ms
240V ac: 40A for 4 ms
24V dc:
15A for
20 ms
120V ac: 25A for 8 ms
240V ac: 40A for 4 ms
24V dc:
15A for
30 ms
Power Supply Usage 68 VA 70 VA 27W 80 VA 82 VA 40W
Power
Supply
Output
5V dc 400 mA
400 mA
(1)
400 mA 600 mA
600 mA
(2)
600 mA
24V dc 350 mA
350 mA
(1)
350 mA 500 mA
500 mA
(2)
500 mA
Sensor Power Output none 250 mA at 24V dc
AC Ripple < 500 mV
peak-to-peak
400 μF max.
(1)
none none 400 mA at 24V dc
AC Ripple < 500 mV
peak-to-pe
ak
400 μF max.
(2)
none
Input Circuit Type 120V ac 24V dc
sink/source
24V dc
sink/source
120V ac 24V dc
sink/source
24V dc
sink/source
Output Circuit Type Relay Relay Relay/FET Relay Relay Relay/FET
Operating Temp. +0°C to +55°C (+32°F to +131°F) ambient
Storage Temp. -40°C to +85°C (-40°F to +185°F) ambient
Operating Humidity 5% to 95% relative humidity (non-condensing)
Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hours each axis
Relay Operation: 1.5G
Shock Operating: 30G; 3 pulses each direction, each axis
Relay Operation: 7G
Non-Operating: 50G panel mounted (40G DIN Rail mounted); 3 pulses each direction, each axis

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
