Page #96 background imageLoading...
Page #96 background image
Publication 1762-UM001D-EN-P - March 2004
A-6 Specifications
Expansion I/O
Specifications
Discrete I/O Modules
Table A.10 Working Voltage (1762-L24BWA,
1762-L40
BWA, 1762-L24BWAR,
1762-L40
BWAR)
Description 1762-L24BWA,
1762-L40
BWA, 1762-L24BWAR,
1762-L40
BWAR
Power Supply Input to Backplane Isolation Verified by one of the following dielectric tests:1836V ac for 1 second or 2596V dc for 1 second
265V
a
c Working Voltage (IEC Class 2 reinforced insulation)
Input Group to Backplane Isolation and
Input Group to Input Group Isolation
Verified by one of the following dielectric tests: 1200V ac for 1 second or 1697V dc for 1 second
75V dc Working Voltage (IEC Class 2 reinforced insulation)
Output Group to Backplane Isolation Verified by one of the following dielectric tests: 1836V ac for 1 second or 2596V dc for 1 second
265V
a
c Working Voltage (IEC Class 2 reinforced insulation).
Output Group to Output Group Isolation Verified by one of the following dielectric tests: 1836V ac for 1 second or 2596V dc for 1 second
265V
ac
Working Voltage (basic insulation) 150V Working Voltage (IEC Class 2 reinforced
insulation)
Table A.11 Working Voltage (1762-L24BXB,
1762-L40
BXB, 1762-L24BXBR,
1762-L40
BXBR)
Description 1762-L24BXB,
1762-L40
BXB, 1762-L24BXBR,
1762-L40
BXBR
Input Group to Backplane Isolation and
Input Group to Input Group Isolation
Verified by one of the following dielectric tests: 1200V ac for 1 second or 1697V dc for 1 second
75V dc Working Voltage (IEC Class 2 reinforced insulation)
FET Output Group to Backplane
Isolation
Verified by one of the following dielectric tests: 1200V ac for 1 second or 1697V dc for 1 second
75V dc Working Voltage (IEC Class 2 reinforced insulation)
Relay Output Group to Backplane
Isolation
Verified by one of the following dielectric tests: 1836V ac for 1 second or 2596V dc for 1 second
265V
a
c Working Voltage (IEC Class 2 reinforced insulation).
Relay Output Group to Relay Output
Group and FET Output Group Isolation
Verified by one of the following dielectric tests: 1836V ac for 1 second or 2596V dc for 1 second
265V
ac
Working Voltage (basic insulation) 150V Working Voltage (IEC Class 2 reinforced
insulation)
Table A.12 General Specifications
Specification Value
Dimensions 90 mm (height) x 87 mm (depth) x 40.4 mm (width)
height including mounting tabs is 110 mm
3.54 in. (height) x 3.43 in. (depth) x 1.59 in. (width)
height including mounting tabs is 4.33 in.
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Operating Temperature 0°C to +55°C (+32°F to +131°F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude 2000 m
eters (656
1 feet)
