Page #46 background image
Publication 1762-UM001D-EN-P - March 2004
3-10 Wiring Your Controller
Sinking and Sourcing
Wiring Diagrams
Any of the MicroLogix 1200 DC embedded input groups can be
configured as sinking or sourcing depending on how the DC COM is
1762-L40BXB
1762-L40BXBR
Group 0 DC COM 0 I/0 through I/3
Group 1 DC COM 1 I/4 through I/7
Group 2 DC COM 2 I/8 through I/23
Table 3.4 Output Terminal Grouping
Controller Outputs
Output Group Voltage Terminal Output Terminal
1762-L24AWA
1762-L24AWAR
Group 0 VAC/VDC 0 O/0
Group 1 VAC/VDC 1 O/1
Group 2 VAC/VDC 2 O/2 through O/3
Group 3 VAC/VDC 3 O4 through O/5
Group 4 VAC/VDC 4 O/6 through O/9
1762-L24BWA
1762-L24BWAR
Group 0 VAC/VDC 0 O/0
Group 1 VAC/VDC 1 O/1
Group 2 VAC/VDC 2 O/2 through O/3
Group 3 VAC/VDC 3 O/4 through O/5
Group 4 VAC/VDC 4 O/6 through O/9
1762-L24BXB
1762-L24BXBR
Group 0 VAC/VDC 0 O/0
Group 1 VAC/VDC 1 O/1
Group 2 VDC 2, VDC COM 2 O/2 through O/6
Group 3 VAC/VDC 3 O/7 through O/9
1762-L40AWA
1762-L40AWAR
Group 0 VAC/VDC 0 O/0
Group 1 VAC/VDC 1 O/1
Group 2 VAC/VDC 2 O/2 through O/3
Group 3 VAC/VDC 3 O/4 through O/7
Group 4 VAC/VDC 4 O/8 through O/11
Group 5 VAC/VDC 5 O/12 through O/15
1762-L40BWA
1762-L40BWAR
Group 0 VAC/VDC 0 O/0
Group 1 VAC/VDC 1 O/1
Group 2 VAC/VDC 2 O/2 through O/3
Group 3 VAC/VDC 3 O/4 through O/7
Group 4 VAC/VDC 4 O/8 through O/11
Group 5 VAC/VDC 5 O/12 through O/15
1762-L40BXB
1762-L40BXBR
Group 0 VAC/VDC 0 O/0
Group 1 VAC/VDC 1 O/1
Group 2 VDC 2, VDC COM 2 O/2 through O/9
Group 3 VAC/VDC 3 O/10 through O/11
Group 4 VAC/VDC 4 O/12 through O/15
Table 3.3 Input Terminal Grouping
Controller Inputs
Input Group Common Terminal Input Terminal
