Publication 1762-UM001D-EN-P - March 2004
Specifications A-7
Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak,
2 hours per ax
is
Relay Operation: 1.5G
Shock Operating: 30G panel mounted, 3 pulses per axis
Relay Operation: 7G
Non-Operating: 50G panel mounted, 3 pulses per axis
(40G DIN Rail mounted)
Agency Certification C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Hazardous Environment Class Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)
Radiated and Conducted Emissions EN50081-2 Class A
Electrical /EMC: The module has passed testing at the following levels:
ESD Immunity (IEC1000-4-2) 4 kV contact, 8 kV air, 4 kV indirect
Radiated Immunity (IEC1000-4-3) 10 V/m, 80 to 1000 MHz, 80% amplitude modulation, +900 MHz keyed carrier
Fast Transient Burst (IEC1000-4-4) 2 kV, 5 kHz
Surge Immunity (IEC1000-4-5) 2 kV common mode, 1 kV differential mode
Conducted Immunity (IEC1000-4-6)
10V, 0.15 to 80 MHz
(1)
(1) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is 30 MHz to 1000 MHz.
Table A.12 General Specifications
Specification Value
Table A.13 Input Specifications
Specification 1762-IA8 1762-IQ8 1762-IQ16
Approximate Shipping
Weight
(With Carton)
209g (0.46 lbs.) 200g (0.44 lbs.) 230 g (0.51 lbs.)
Voltage Category 100/120V ac
24V dc (sink/source)
(1)
24V dc (sink/source)<secondary
footnote>(1)
Operating Voltage Range 79V ac to 132V ac at 47 Hz to 63 Hz 10 to 30V dc at 30°C (86°F)
10 to 26.4V dc at
55°C (131°F)
10 to 30V dc at 30°C (86°F)
10 to 26.4V dc at
55°C (131°F)
Number of Inputs 8 8 16
Bus Current Draw (max.) 50 mA at 5V dc (0.25W) 50 mA at 5V dc (0.25W) 60 mA at 5V dc (0.3W)
Heat Dissipation (max.) 2.0 Watts 3.7 Watts 4.2 Watts at 26.4V
5.3 Watts at 30V
Signal Delay (max.) On Delay: 20.0 ms
Off Delay: 20.0 ms
On Delay: 8.0 ms
Off Delay: 8.0 ms
On Delay: 8.0 ms
Off Delay: 8.0 ms
