Publication 1762-UM001D-EN-P - March 2004
Specifications A-19
Non-linearity (in percent full scale) < ±0.5% < ±0.5%
Open and Short-Circuit Protection Continuous Continuous
Output Protection ±32 mA ±32 mA
(1) Includes offset, gain, non-linearity and repeatability error terms.
Table A.25 Output Specifications
Specification 1762-IF2OF2 1762-OF4
Table A.26 Valid Input/Output Data Word Formats/Ranges for 1762-IF2OF2
Normal Operating Range Full Scale Range RAW/Proportional Data Scaled-for-PID
0V to 10V dc 10.5V dc 32760 16380
0.0V dc 0 0
4mA to 20mA 21.0mA 32760 16380
20.0mA 31200 15600
4.0mA 6240 3120
0.0mA 0 0
