Allen-Bradley MicroLogix 1200 User Manual

1 Publication 1762-UM001D-EN-P - March 2004
Summary of Changes
The information below summarizes the changes to this manual since
the last printing.
To help you find new and updated information in this release of the
manual, we have included change bars as shown to the right of this
paragraph.
The table below lists the sections that document new features and
additional or updated information about existing features.
For this information See
MicroLogix 1200 controllers with the
additional communications port
(Programmer/HMI Port)
• hardware features
• firmware revision history
• description
• new 6 catalog numbers
• application example
• specifications
page(s):
• 1-1
• 1-5
• 1-6
• 4-1
• 4-1
• A-1
Programmer/HMI Port
• location
• configuration
• supported protocol
• no LED indicator provided
page(s):
• 1-1
• 4-2
• 4-2
• C-1

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
