382 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 8 Monitor the Switch
Table 100 - Stratix 5410 Port Status Indicators
Mode Status Description
Status In Status mode, the port status indicators show the connection and activity status of the port. Status mode is the default mode. You can choose Status mode via
the View pull-down menu in Device Manager. You can also choose Status mode by pressing the Disp. Mode button on the physical switch until all mode status
indicators on the switch turn off.
Off No link present on the port.
Solid green Port link; no activity.
Flashing green and off Link is active and healthy.
Alternating green and amber There is a fault or error on the link.
Solid amber The port is disabled.
Speed In Speed mode, the port status indicators show the operating speed of the ports.
Ports 1…24 Off The port is not operating.
Solid amber The port is operating at 10 Mbps.
Solid green The port is operating at 100 Mbps.
Flashing green The port is operating at 1000 Mbps.
Ports 25…28 Off The port is not operating.
Solid green The port is operating at 1000 Mbps
Flashing green The port is operating at 10 Gbps.
Duplex In Duplex mode, the port status indicators show the Duplex mode (Full-duplex or Half-duplex) of the ports. The 10/100/1000 ports operate only in Full-duplex
mode.
Off The port is not operating.
Solid amber The port is operating in Half-duplex mode.
Solid green The port is operating in Full duplex mode.
PRP In PRP mode, the port status indicators show the status of Parallel Redundancy Protocol (PRP). To configure PRP, see
page 297.
Off PRP is disabled or not in use on the port.
Solid green PRP is configured and active on the port.
Solid amber PRP is configured on the port and has a redundancy fault.
DLR—Not functional as of the current release.
Power
or
PoE
In Power or PoE mode, the port status indicators show the status of PoE.
The Power mode available via the View pull-down menu in Device Manager is the same as the PoE mode available via the Disp. Mode button on the physical
switch.
Off PoE is not enabled on the port.
Solid green PoE is enabled on the port and functioning properly.
Alternating green and amber PoE is enabled on the port, but power is disconnected or failing on this low priority port.
Flashing amber PoE is enabled on the port, but power is disconnected or failing on this high priority port.
Solid amber PoE is enabled on the port, but has failures.
