Allen-Bradley Ultra3000 User Manual

Publication 2098-IN003E-EN-P — April 2004
B-6 Interconnect Diagrams
The Ultra3000 (2098-DSD-HVxxx-xx and -HVxxxX-xx) power wiring
with 24V dc control string is shown in the figure below. For the
control string diagram with 120V ac input refer to Figure B.18.
Figure B.4
Typical Power Wiring of Ultra3000 System
(2098-DSD-HVxxx-xx and -HVxxxX-xx)
Note: Refer to Figure 2.26 in the chapter Ultra3000 Connector Data
for more information on the relay output.
TB1
DC+
DC-
W
V
U
L2
L3
CN1
43
44
L1
TB2
1
2
3
L3
L2
L1
L1 AUX
L2/N AUX
43
44
CN1
43
44
Ultra3000
Digital Servo Drives
2098-DSD-HVxxx-xx and
-HVxxxX-xx
Note 14
AC Input Power
Connections
Motor Power
Connections
Three-Phase
AC Line Filter
Note 7
Three-Phase Input
230-480V ac RMS
Fused Disconnect
or Circuit Breaker*
Note 1
Isolation
Transformer*
Note 2
Chassis
Bonded Cabinet
Ground Bus*
Terminal Blocks*
Note 3
To additional
Ultra3000 drive
Three-Phase
Motor Power
Connections
Note 12
Cable Shield
Clamp
Note 9
* INDICATES USER-SUPPLIED COMPONENT
STOP*
START*
CR1*
CR1*
CR1*
M1*
Refer to Attention statement (Notes 10, 11)
N.O. Relay Output+
N.O. Relay Output-
Note 20
24V dc
Neutral
M1*
Note 8
External Passive
Shunt Connections
(refer to figures
beginning on B-7)
Input Fusing*
Notes 4 and 5
Three-Phase AC Line
50/60 Hz
Note 6
