Allied Telesis AT-8000S Series Cli Reference Guide

QoS Commands
Page 157
Example
The following example displays QoS attributes when QoS is disabled on the device.
priority-queue out num-of-queues
The priority-queue out num-of-queues Global Configuration mode command configures the number of expedite
queues. Use the no form of this command to return to the default configuration.
Syntax
priority-queue out num-of-queues number-of-queues
no priority-queue out num-of-queues
Parameters
•
number-of-queues — Specifies the number of expedite queues. The expedite queues are the queues with
higher indexes. (Range: 0-4)
Default Configuration
All queues are expediting queues.
Command Mode
Global Configuration mode
User Guidelines
When the specified number of expedite queues is 0, the Strict Priority scheduling method is used.
When the specified number of expedite queues is 4, weights are defined as 1, 2, 4 and 8.
Example
The following example configures the number of expedite queues as 0.
rate-limit
The rate-limit Interface Configuration mode command limits the rate of the incoming traffic. The no form of this
command is used to disable rate limiting.
Syntax
rate-limit rate
no rate-limit
Parameters
•
rate — Maximum kilobits per second of ingress traffic on a port. (Range: 62K - 100M).)
Console show qos
Qos: disable
Trust: dscp
Console(config)#
priority-queue out num-of-queues 0
