Allied Telesis AT-8000S Series Cli Reference Guide

Page 204
Not approved by Document Control. For review only.
Allied Telesis
Command Line Interface User’s Guide
User Guidelines
There are no user guidelines for this command.
Example
The following example disables spanning-tree on Ethernet port 1/e5.
spanning-tree cost
The spanning-tree cost Interface Configuration mode command configures the spanning tree path cost for a
port. Use the no form of this command to return to the default configuration.
Syntax
spanning-tree cost cost
no spanning-tree cost
Parameters
•
cost — Path cost of the port (Range: 1 - 200,000,000)
Default Configuration
Default path cost is determined by port speed and path cost method (long or short) as shown below:
Command Modes
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
The path cost method is configured using the spanning-tree pathcost method Global Configuration mode
command.
Example
The following example configures the spanning-tree cost on Ethernet port 1/e15 to 35000.
Console(config)# interface ethernet 1/e5
Console(config-if)# spanning-tree disable
Interface Long Short
Port-channel 20,000 4
Gigabit Ethernet (1000 Mbps) 20,000 4
Fast Ethernet (100 Mbps) 200,000 19
Ethernet (10 Mbps) 2,000,000 100
Console(config)# interface ethernet 1/e15
Console(config-if)# spanning-tree cost 35000

Allied Telesis AT-8000S Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Humidity	5% to 95% non-condensing
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
VLANs	4, 094
Layer 3 Features	Static routing, RIP v1/v2
Management	Web-based
Operating Humidity	10% to 90% non-condensing
