WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL
Copyright © 1996 General Motors Corp.
CUSTOMER-FURNISHED VIW/VIM CONNECTOR
CROSS-REFERENCE CHART
Connector Navistar 29516972 Navistar 29516972 Navistar 29516972 Freightliner 29517161 Freightliner 29517161 Freightliner 29517161
Description VIW A 29511372 VIW B 29511373 VIW C 29511374 VIM A 12066195 VIM B VIW
Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color
105 9 Green 108 8 Yellow 117 3 Green 112 D Violet 123 D Violet 105 1 Green
119 5 Yellow 136B 7 Red 118 5 Blue 113 E White 136A E Red 117 16 Green
137 12 Orange 142A 3 White 153 6 Yellow 114 F White 136C F Red 118 2 Blue
142B 11 White 143B 6 Black 155 2 Green 115 A Green 143A A Black 119 3 Yellow
151B 10 Blue 151A 4 Blue 161B 1 Yellow 125 C White 143C B Black 137 5 Orange
161C 1 Yellow 154 12 White 312CM 10 Yellow 132 B Orange 146A G Yellow 142B 6 White
163 2 Blue 160 10 Violet 312NO 12 Blue 157 C Violet 151B 7 Blue
325CM 3 Yellow 168 9 Yellow 312NC 11 Green 158 H Orange 153 8 Yellow
325NC 4 Green 315 5 White 314CM 7 Yellow 154 12 White
332CM 6 Yellow 346 1 Orange 314NC 8 Green 155 9 Green
332NC 7 Green 357UF 11 White 314NO 9 Blue 161B 13 Yellow
332NO 8 Blue 358 2 White 163 14 Blue
Connector Navistar 29516972 Navistar 29516972 Ford 29515707&8 Ford 29515704 Gillig 29511644 Gillig 29511644
Description Rev. Warn/Neut Start Power/Ground Fuse 12033769 Fuse 12033769 6-Way Shroud #47 6-Way Tower #51
12084891 15300002 12010975 12015799
Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color
313CM A Yellow 336B A Red 136E A Red 136D A Red 136A A Red 158 A Red
313NO B Blue 343B B Black 136F B Red 136E B Red 136C B Red B
323NO D Blue 146A C Yellow 113 C White
323CM E Yellow D 157 D Violet
143C E Black 123 E Violet
143F F Black 115 F Green
Connector Freightliner 29507731 Freightliner 29507731 Freightliner 29507731 Freightliner 29507731 Freightliner 29520928 Freightliner 29520928
Description 2-Fuse Block Relay Holder A Relay Holder B Relay Holder C 2-Fuse Block Relay Holder A
29509584 29509583 29509583 29509583 29509584 29509583
Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color Wire # Term. # Color
14 1A White GND 30 White 30 20C 30 White 14 1A White 15E 30 Black
136D 2A Red 115 85 Green GND 85 White 113 85 White 136D 1B Red GND 85 White
146A 2B Yellow 86 123 86 Violet 20B 86 White 2A 123A 86 Violet
87 87 20A 87 White 146A 2B Yellow 15 87 Black
87A 87A 87A 87A
Connector Freightliner 29520928
Description Relay Holder B
29509583
Wire # Term. # Color
20B 30 White
113 85 White
20A 86 White
304 87 White
87A
Foldout D–2. Customer-Furnished VIW/VIM Connector Cross-Reference Chart
