WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL
E–50 Copyright © 1998 General Motors Corp.
APPENDIX E — CONNECTOR PART NUMBERS, TERMINAL PART
NUMBERS, TOOL PART NUMBERS, AND REPAIR INSTRUCTIONS
Figure E–14. EPC Connectors (Ford 16-Way Bulkhead)
A
C
E
B
D
V01695
J 38125-7
VIEW B
VIEW A
RECEPTACLE
SECONDARY LOCK
J 38125-13
WIRE AND TERMINAL
PLUG
SECONDARY LOCK
INDIVIDUAL
TERMINAL
LOCKING
LEVERS
INDIVIDUAL TERMINAL
LOCKING LEVERS
REMOVE
INSTALL
REMOVE
INSTALL
