WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL

APPENDIX D — WIRE/CONNECTOR CHART

Figure D–31. Resistance Module Type 7 — Dedicated Pedal

RESISTANCE MODULE TYPE 7

Terminal No. Color

A Green

B Yellow

C White

V00573

+5V (W)

SIGNAL (Y)

GND (G)
