Allworx Verge IP Phone Series User Guide
866.ALLWORX * +1 585 421 3850 Page 81
www.allworx.com
Version: D Revised: June 1, 2017
Appendix A Icons
The Verge IP phone series uses the following icons:
Contacts Visual or Audio Voicemail
Presence / DND Intercom
Transfer Hold
Mute Headset
Speaker Phone More soft key options available
Contacts locked. Contacts unlocked.
Bluetooth disconnected. Bluetooth connected.
Do Not Disturb activated. Reach Remote Control, Interact, or
Allworx TAPI is connected and
controlling the Verge IP phone.
Presence - On Vacation. Presence - On Business Trip.
Presence - Away. Presence - Busy.
Presence - At A Meeting. Presence - At Home.
Allworx User and System Contact
badge.
Allworx User Contact avatar, if no
image is available.
Allworx System Contact - example:
conference room.
Allworx System Contact - Auto
Attendant.
Allworx System Contact - Door Relay. Allworx System Contact - Conference
Center.
